训练器软件Trainer Software
A320 FTD 5级训练器采用空客数据包,集成了数据包中的飞行模型、飞行控制模型、部分航电系统模型等,通过驾驶舱仿真系统、操纵负荷系统、仪表仿真系统以及视景系统,为飞行训练营造了逼真的训练环境。
The A320 FTD Level 5 trainer uses Airbus data packages, integrating the flight model, flight control model, and some avionics system models from the package. Through the cockpit simulation system,control loading system, instrument simulation system, and visual system, it creates a realistic training environment for flight training.
训练器硬件Trainer hardware
全舱硬件由莱特兄弟自主研发完成,其硬件包括带操纵负荷的正副驾驶驾驶杆、带操纵负荷的正副驾驶联动脚舵、前后顶板、主仪表板、油门台、断路器墙及驾驶员座椅。设备采用仿真内饰。用户可根据航空公司及航校场地选装球形虚像视景系统、球形实像视景系统、柱幕视景系统。训练器硬件仅有部分货架类成品部件来自市场采购,设备稳定性好,用户使用售后成本低。设备可用于航校、航空公司的飞行员培训。
The full cabin hardware is independently developed by the Wright Brothers, including the control-loaded pilot and co-pilot control sticks,control-loaded pilot and co-pilot linked rudder pedals, overhead panels,main instrument panel, throttle quadrant, circuit breaker wall, and pilot seats. The equipment uses simulated interiors. Users can choose from a spherical virtual image visual system, a spherical real image visual system, or a column screen visual system based on the airline and flight school’s site. The trainer hardware consists partly of off-the-shelf components, providing good equipment stability and low post-sale costs for users. The equipment is suitable for flight training at flight schools and airlines.
产品特点:
- 依据真实 A320 飞机驾驶舱复制
- 可以提供 CEO 2.0 数据包
- 使用空客原厂数据包
- 可选开放式的或封闭式的教员舱
- 友好的教员操纵台,使用触摸显示器或平板电脑
- 具有 330 个模拟故障
- 可选虚像准直视景、实像非准直视景(FOV 220 * 40 度)
- 模拟全功能 FMS 或选择真机 FMS 模块
- 副翼、升降舵、方向舵三通道操纵负荷
- 符合认证要求的完整 QTG 功能
- 模拟 WXR、TCAS、EGPWS 等
- 全球地景和导航数据库
- 俯仰、横滚、偏航三通道操纵负荷
Product Features:
- Based on the real A320 cockpit replica
- Provides CEO 2.0 data package
- Uses original Airbus data packages
- Optional open or enclosed instructor station
- User-friendly instructor console, using a touchscreen or tablet
- Features 330 simulated malfunctions
- Optional virtual image collimated visual system, real image non-collimated visual system (FOV 220 * 40 degrees)
- Simulates full-function FMS or choose real FMS modules
- Three-channel control loads for aileron, elevator, and rudder
- Full QTG functionality compliant with certification requirements
- Simulates WXR, TCAS, EGPWS, etc.
- Global scenery and navigation database
- Pitch, roll, and yaw three-channel control loading
